01Profiles for machines
T-slot framing
20–45 series frames for machine bases, workstations and guards. See T-slot profiles.
Linear-motion bodies
Actuator housings and guide-rail bases with machined datum faces.
Conveyor sections
Side rails, return rails and belt supports with integrated slots.
Guarding & enclosures
Panel frames and door profiles for machine guarding.
Brackets & plates
Extruded then cut into brackets — cheaper than machining from block.
Cable management
Cable ducts and covers that clip into framing slots.
02What matters in machine building
- Straightness and twist. Extrusion tolerances suit framing; linear guides need machined datum faces, which we mill after extrusion.
- Stiffness. Deflection usually governs before strength — size members by their second moment of area (Ix, Iy).
- Wear and appearance. Clear or black anodizing protects frames in daily use.
- Assembly time. Pre-cut, pre-tapped and labelled parts cut hours from every build.
Section properties for standard framing are in the T-slot library.
03How we supply machine builders
Send a cut list
Profiles, lengths, end tapping and hole positions — spreadsheet or drawing.
Machining
Cut, tapped, drilled and milled to the list.
Kitting
Parts packed and labelled per machine or per sub-assembly.
Repeat builds
The same list re-ordered with identical results.
04Frequently asked questions
Why use aluminum extrusions instead of welded steel for machine frames?
Aluminum framing is lighter, needs no welding or painting, resists corrosion, and can be modified with standard fasteners. It suits machines that change during their life. Welded steel remains better for very heavy, high-vibration bases.
Can you machine datum faces for linear guides?
Yes. Extruded surfaces follow standard straightness tolerances, so faces that locate linear guides or bearings are milled after extrusion to the flatness your drawing requires.
Do you kit parts per machine?
Yes. Cut and machined parts can be packed and labelled per machine or sub-assembly, following your bill of materials.
